McCAULEY 14 Ton Dump Trailer
McMAULEY heavy duty dump trailers are specially designed for today's toughest conditions.
SPECIFICATION
Overall length . . . 5m
Overall height . . . 2.21m
Overall width . . . . 2.5m
Body length . . . . . 3.70m
Body width . . . . . . 2.10m
Body depth . . . . . . 0.90m
Tip angle . . . . 70 degrees
Wheel base . . . . . 2.30m
Hydraulic Back Door.
Spring Drawbar.
Rocking beam axles
fitted with 15R-22.5
Tyres.
Tapered body for easy discharge of difficult
loads.
brakes on all wheels.
Full road lights & Mudguards.
SPECIFICATION
Overall length . . . 5m
Overall height . . . 2.21m
Overall width . . . . 2.5m
Body length . . . . . 3.70m
Body width . . . . . . 2.10m
Body depth . . . . . . 0.90m
Tip angle . . . . 70 degrees
Wheel base . . . . . 2.30m
Hydraulic Back Door.
Spring Drawbar.
Rocking beam axles
fitted with 15R-
Tapered body for easy discharge of difficult
loads.
brakes on all wheels.
Full road lights & Mudguards.
