New Holland 6 cylinder turbocharged @ 150hp
Producing very high torque.
Shuttle Command with 20 forward and 16 reverse gears, using conventional
dry plate clutch for a
very smooth engagement.
Open centre with 53.1 lpm@ 190 Bar. 2 spool valves.
Max lift on rear linkage With one assist ram 5570kg
3 speeds 540, 750 & 1000
Giving a massive 145hp on the PTO.
Height to top of cab 2.78m
Ground clearance 0.27m
Turning radius 9.22m
Tyres front 14.9R28
Tyres rear 18.4R38
