New Holland TM 150
SPECIFICATIONS

ENGINE:
New Holland  6 cylinder turbocharged @ 150hp
Producing very high torque.

TRANSMISSION:
Shuttle Command with 20 forward and 16 reverse gears, using conventional
dry plate clutch for a
very smooth  engagement.

HYDRAULICS:
Open centre with 53.1 lpm@ 190 Bar. 2 spool valves.
Max lift  on rear linkage With one assist ram 5570kg

PTO:
3 speeds 540, 750 & 1000
Giving a massive 145hp on the PTO.

             STATIC
      DIMENSIONS:
Height to top of cab 2.78m
Length                     4.61m
Wheelbase               2.72m
Ground clearance     0.27m
Turning radius           9.22m
Weight                   5250kg
Tyres front            14.9R28
Tyres rear             18.4R38
